Outdoor Single Color DIP LED Display Module Series

Outdoor Single Color SMD LED Display Module Series

Color

Red

Green

Yellow

Blue

White

RG

Red

Green

Yellow

Blue

White

RGB

Pixel Configuration

1R

1G

1Y

1B

1W

1R1G

1R

1G

1Y

1B

1W

1R1G1B

Brightness (cd/sqm)

1500

6000

1300

1800

8000

5500

800

1000

2000

500

2000

1800/2800

Model

P10

P10

P10

Module Pixel (W*H)

32*16

32*16

32*16

Module Size (W*H mm)

320*160

320*160

320*160

Lamp

DIP546

SMD2835

SMD2727

Scan Mode

1/4

1/4

1/4

Module Parameter

Pixel Pitch

10mm

Pixel configuration

SMD3535 Black

Density

10,000 pixels/㎡(real pixel)

Module Resolution

32pixel(L) * 16pixel(H)

Module Dimension

320mm(L) * 160mm(H) * 25mm(D)

Driving Mode

Constant current, 1/4 duty

Module Mask

Pure black mask—high contrast screen

Electricity Parameter

Optical Ratings

Brightness

≥6,000 cd/㎡

Viewing Angle

120°(Horizontal); 120°(Vertical)

Best Viewing Distance

≥10m

Gray Grade

16,384 levels for each color

Display Color

4.39 Trillion Colors

Brightness Adjustment

100 grades by software or automatically by sensor

Max. Power Consumption

28W

Control System

Correction Scale Level

12bits

Frame Frequency

≥60Hz

Screen Refresh Frequency

≥1,920Hz

Gamma Correction

-5.0～5.0

Reliability

Working Temperature

-20～+60 ºC

Stored Temperature

-30～+70 ºC

Working Humidity

10%～90% RH

Lifetime

100,000 hours

MTBF

5000 hours

Continuous Working Time

≥72 hours

Protection Grade

IP65

Out of Control Pixel Rate

≤0.01%
